There are a lot of DMX fixtures in the world. Table 1 lists the DMX fixtures that Finale 3D currently supports with predefined fixture definitions, standard effects, and simulations. If your fixture matches one of these, or is compatible with it, then you are in luck — in Finale 3D simply right click your position and configure it as a DMX fixture from the menu, and choose your fixture. If your fixture isn’t on this list, please download or scan the user’s manual of your fixture and send it to Finale support, asking us to add support for your fixture. As of November, 2025 Finale’s DMX support team is able to add fixture implementations within a week or two depending on the complexity.
Table 1 – Supported fixtures
| Brand ID | ID | Manufacturer | Fixture Name | Category | Number of DMX Channels | Manual and Notes |
|---|---|---|---|---|---|---|
| ADJ | 045 | ADJ | Fog Fury Jett Fog Jet Machine | Fog Jet Machine | 7CH | 28596-ADJFOGFURYJETTPROUserManual.pdf |
| ADJ | 082 | ADJ | Inno Pocket Spot Pearl Moving Head | Moving Head | 9CH | inno_pocket_spot_pearl.pdf |
| ADJ | 049 | ADJ | QWH12X RGB Par Light | Par Light | 8CH | Adj Flat Par QWH12X.pdf |
| ANO | 206 | Anonymous | 12W RGBW Pinspot Spotlight | Spotlight | 6CH | MINI SPOT CHANNEL map.pdf |
| ANO | 095 | Anonymous | 150W Mini Beam Spot LED Moving Head | Moving Head | 12CH | 150W Beam Spot LED Moving Head Manual.pdf |
| ANO | 036 | Anonymous | 5 Head Flamer Flame Machine | Flame Machine | 7CH | Fan Flame Machine.pdf |
| ANO | 085 | Anonymous | Beam 230 7R Moving Head | Moving Head | 16CH | Beam 230w 7r user manual.pdf |
| ANO | 005 | Anonymous | Easy Dancing 36x1W Par Light | Par Light | 7CH | easydancing-manual.pdf |
| ANO | 204 | Anonymous | ML-B150 150W LED Beam Moving Head | Moving Head | 17CH | ML-B150-Pyrotechnics-QR.pdf |
| ANO | 072 | Anonymous | RGB Fog Jet Machine | Fog Jet Machine | 7CH | Fog Machine.pdf |
| ANO | 059 | Anonymous | Small Steel Gun 120W Moving Head | Moving Head | 16CH | MANUAL.pdf |
| ANO | 006 | Anonymous | Spray The Fire Flame Machine | Flame Machine | 2CH | spray-the-fire-user-manual.pdf |
| ANO | 067 | Anonymous | Water Low Fog 3000W Fog Jet Machine | Fog Jet Machine | 2CH | Water Low Fog 3000W.pdf |
| ATM | 063 | AtmosFEAR | Hex Jet Fog Jet Machine | Fog Jet Machine | 10CH | atmosfear-hex-jet_manual_rev_c.pdf |
| AUV | 035 | Auvi | Spark Sparks Machine | Sparks Machine | 3CH | auvi-spark-user-manual.pdf |
| BET | 090 | Betopper | LM70S DJ Mini Moving Head | Moving Head | 9CH | BETOPPER Moving Head LM70 LM70S Manual.pdf |
| BET | 050 | BETOPPER | P54 54×1.5W RGB Par Light | Par Light | 7CH | LPC007-LPC008_LPC08-H_BETOPPER_DJ_PAR_Light_User_Manual.pdf |
| BMZ | 041 | BeamZ | BBP60 Par Light | Par Light | 10CH | beamz-bbp60-manual |
| CHV | 091 | Chauvet | 260X Intimidator Spot Moving Head | Moving Head | 14CH | Intimidator_Spot_260X_UM_Rev2.pdf |
| CHV | 079 | Chauvet | EZpar 64 Par Light | Par Light | 8CH | EZpar_64_RGBA_UM_Rev1_WO-1.pdf |
| CHV | 078 | Chauvet | Geyser RGB Fog Jet Machine | Fog Jet Machine | 8CH | GeyserRGB_UM_Rev8_WO-1.pdf |
| CHV | 209 | Chauvet | Rogue Outcast 2 Moving Head | Moving Head | 20CH | Rogue_Outcast_2_Hybrid_UM_Rev4.pdf |
| CHV | 031 | Chauvet | Scorpion Dual Laser | Laser | 10CH | scorpion-manual.pdf |
| CHV | 051 | Chauvet | Slim Par 56 Par Light | Par Light | 7CH | SlimPAR_56_UM_Rev1.pdf |
| COB | 048 | Cobra | 36x1W Par Light 7CH | Par Light | 7CH | DMX LED Digital Display Par Lighting Instructions.pdf |
| DJX | 219 | DJXFLI | 180W Moving Head | Moving Head | 14CH | DJXFLI 180W Moving Head Light (scan).pdf |
| DJX | 093 | DJXFLI | Beam 120W Beam + Spot Moving Head | Moving Head | 12CH | DJXFLI 120 Beam+Spot LED moving head.pdf |
| DOM | 092 | Dominar | Beam IP Moving Head | Moving Head | 14CH | Dominar IP manual.pdf |
| ENE | 094 | Erik Nelson | Diamond Pro Venue 460 Moving Head | Moving Head | 25CH | PRO-460.pdf |
| EWY | 230 | Eway | LUX-FR2 Flame Machine | Flame Machine | 6CH | lux-Fr2 Manual.pdf |
| EXP | 032, 033 | Explo | GX2 Flame Machine | Flame Machine | 1CH, 1CH | GX2 v2.0 (ENG).pdf |
| EXP | 034 | Explo | GX3 Power Flame Flame Machine | Flame Machine | 4CH | GX3 Power Flame v1.3 EN.pdf |
| EXP | 001 | Explo | X2 Wave Flamer Flame Machine | Flame Machine | 6CH | X2 Wave Flamer v2.0 ENG.pdf |
| FRG | 064 | Froggy’s Fog | Hyperion D6 Fog Jet Machine | Fog Jet Machine | 17CH | ffm-hyperion-d6-froggys-fog-fog-machine-user-manual2.pdf |
| GEN | 217 | Generic | Generic 128 Safety Channel | Safety Channel | 1CH | (Use for generic flame machines w/ separate safety channel base address, ON = 128) |
| GEN | 018 | Generic | Generic 255 Safety Channel | Safety Channel | 1CH | (Use for generic flame machines w/ separate safety channel base address, ON = 255) |
| GEN | 008 | Generic | Generic Dimmer Flame Machine | Flame Machine | 1CH | (Use for generic 1CH variable height flame machines) |
| GEN | 069 | Generic | Generic Dimmer Spotlight | Spotlight | 1CH | (Use for generic 1CH dimmer spotlight fixture) |
| GEN | 007 | Generic | Generic ON/OFF Flame Machine | Flame Machine | 1CH | (Use for generic 1CH ON/OFF flame machines) |
| GEN | 068 | Generic | Generic ON/OFF Spotlight | Spotlight | 1CH | (Use for generic 1CH spotlight fixture, ON = 255) |
| GLX | 002 | Galaxis | G-Flame Flame Machine | Flame Machine | 1CH + separate safety channel [016] | User-Manual-G-Flame-V2.40-007.pdf |
| GLX | 016 | Galaxis | Safety Channel | Safety Channel | 1CH | User-Manual-G-Flame-V2.40-007.pdf |
| HAN | 083 | Hansol | Hurricane-AW Flame Machine | Flame Machine | 19CH | Hurricane AW manual.pdf (Standard effects for this fixture do not include the predefined angle single shots or “autoshow” programs. Standard effects automatically set the electric spark channel with each event prior to the event time.) |
| HAN | 057 | Hansol | Sunshine Fixture: 5 Head w/ Pilot Only Flame Machine | Flame Machine | 5CH + separate safety channel [058] | Sunshine Single 16L & 30L.pdf |
| HAN | 055 | Hansol | Sunshine Fixture: 5 Head w/ Safety And Pilot Flame Machine | Flame Machine | 5CH + separate safety channel and pilot light [056] | Sunshine Single 16L & 30L.pdf |
| HAN | 058 | Hansol | Sunshine Pilot Only: Pilot At +0 | Flame Machine | 1CH | Sunshine Single 16L & 30L.pdf (This separately addressed safety channel fixture has one channel, which is the pilot light acting as a safety channel) |
| HAN | 056 | Hansol | Sunshine Safety And Pilot: Safety At +0 And Pilot At +1 | Safety Channel | 2CH | Sunshine Single 16L & 30L.pdf (This non-standard safety channel fixture has two channels, not one, a safety channel at +0 and pilot at +1) |
| HAN | 053 | Hansol | Volcano Flame Machine | Flame Machine | 1CH + separate safety channel [054] | Volcano0811-Black-1-1.pdf |
| HAN | 054 | Hansol | Volcano Pilot Light / Safety Channel | Safety Channel | 1CH | Volcano0811-Black-1-1.pdf (Pilot light acting as safety channel; the fixture user’s manual states that the pilot light must be configured as channel 100) |
| HGH | 077 | High End | Uno Moving Head | Moving Head | 15CH | uno.pdf |
| KRM | 074 | Karma | LED Par120 Par Light | Par Light | 8CH | karma-LED_PAR120_17105.pdf |
| KTV | 207 | KTV Lights | A3 RGB Animation Laser Performer Laser | Laser | 16CH | A3 RGB Animation Laser Performer Manual.pdf |
| MFX | 003, 004 | MagicFX | Flamaniac 5-Head Flame Machine | Flame Machine | 5CH-MODE1, 1CH-MODE2 + separate safety channel [017] | manual_flamaniac_eng-2017.pdf |
| MFX | 025 | MagicFX | Flameblazer Flame Machine | Flame Machine | 1CH + separate safety channel [017] | MAGICFX_FLAMEBLAZER_MANUAL_HR.pdf |
| MFX | 017 | MagicFX | Safety Channel / Device Enable | Safety Channel | 1CH | manual_flamaniac_eng-2017.pdf |
| MFX | 019 | MagicFX | Sparxtar Sparks Machine | Sparks Machine | 2CH + separate safety channel [017] | MAGICFX_SPARXTAR_MANUAL.pdf |
| MFX | 021, 022, 023 | MagicFX | Stage Flame Machine | Flame Machine | 1CH-Aerosol, 1CH-Propane, 2CH-Aerosol+Propane + separate safety channel [017] | MAGICFX_STAGE-FLAME_MANUAL.pdf |
| MFX | 233 | MagicFX | Firestorm 5-Head Flame Machine | Flame Machine | 5CH + separate safety channel [017] | MAGICFX_FIRESTORM_v01_web.pdf |
| MFX | 234 | MagicFX | Flameblazer 5-Head Flame Machine | Flame Machine | 5CH + separate safety channel [017] | MAGICFX_FLAMEBLAZER 5-WAY_v01_web.pdf |
| MOK | 084 | Moka | E11 Cold Sparks Machine | Sparks Machine | 2CH | MK-E11.pdf |
| MOK | 044 | Moka | H-E01 Genius Flame Machine | Flame Machine | 2CH | H-E01 User Manual(说明书) |
| MOK | 043 | Moka | H-E03 Triple Way Flame Machine | Flame Machine | 6CH | H-E03 User Manual(说明书).pdf |
| MOK | 076 | Moka | H-E04 Hi Flame Flame Machine | Flame Machine | 7CH | H-E04 HI FLAME MACHINE英文说明书.pdf |
| MOK | 221 | Moka | H-E05 5-Head Flame Machine | Flame Machine | 8CH | User Manual_H-E05.pdf |
| MOK | 212 | Moka | MK-P11 Par Light | Par Light | 11CH | MK-P11 par light.pdf |
| MOK | 220 | Moka | P-350 Waterproof 350W Beam Light Moving Head | Moving Head | 16CH | 350W防水光束灯 英文说明书.pdf |
| MOK | 042 | Moka | P18 18x18W Washer Light Wash Light | Wash Light | 11CH | MK-P18 18X18W 6in1 LED wall washer light.pdf |
| MOK | 211 | Moka | PF-1800 Wave Flame Machine | Flame Machine | 9CH | User Manual_PF-1800.v3（第三版）.pdf |
| MRQ | 052 | MARQ | Gesture Spot 100 15W LED Moving Head | Moving Head | 11CH | Gesture Spot 100 – User Guide – v1.3.pdf |
| MTR | 040 | Le Maitre | Safety Channel | Safety Channel | 1CH | Salamander Manual 1.3.pdf |
| MTR | 039 | Le Maitre | Salamander Flame Machine | Flame Machine | 1CH | Salamander Manual 1.3.pdf |
| OPP | 030 | OPPSK | Ball Strobe Chase And Laser Disco Ball | Disco Ball | 15CH | disco-manual.pdf |
| OPP | 073 | OPPSK | Wall Washer Light Bar | Light Bar | 8CH | LightBar.pdf |
| RCK | 080 | Rockville | Battery Par 50 Par Light | Par Light | 6CH | BatteryPar50_Manual_OL.pdf |
| RCK | 071 | Rockville | Battery Strip 24 RGBW Light Bar | Light Bar | 9CH | BATTERY STRIP 24_Manual_OL.pdf |
| RCK | 075 | Rockville | BestPAR60 Par Light | Par Light | 10CH | BestPAR60_Manual.pdf |
| RIU | 205 | Riukeo | ML-B080 80W LED Beam Moving Head | Moving Head | 20CH | ML-B080-Riukoe-moving-head-fixture-manual.pdf |
| SAH | 088 | Sahauhy | 12 LED RGBW Par Light | Par Light | 8CH | sahauhy-mini-par.pdf |
| SFX | 060 | SpecialFX.it | 18x12W IP65 RGBWAU Par Light | Par Light | 10CH | user manual —-18x12W waterproof 6in1 led par light.pdf |
| SFX | 061 | SpecialFX.it | ML-CS01 Cold Sparks Machine | Sparks Machine | 2CH | User manual –cold spark machine 2021 10.pdf |
| SHD | 218 | Shehds | 380W Beam With Ring Moving Head | Moving Head | 19CH | SHEHDS-IP65-380W.pdf |
| SHO | 216 | Showven | Safety Channel | Safety Channel | 1CH | cFlamer mVolcano MANUAL.pdf |
| SHO | 062 | Showven | SonicBoom Plus SmokeJet Fog Jet Machine | Fog Jet Machine | 14CH | SONICBOOM PLUS SMOKEJET.pdf |
| SHO | 070 | Showven | SonicBoom X SmokeJet Fog Jet Machine | Fog Jet Machine | 11CH | SONICBOOM X MANUAL -20210407.pdf |
| SHO | 015 | Showven | Sparkular Cyclone Sparks Machine | Sparks Machine | 2CH | sparkular-cyclone-user-manual.pdf |
| SHO | 086 | Showven | Sparkular Jet Sparks Machine | Sparks Machine | 2CH | 8137_sparkular-jet-en.pdf |
| SHO | 014 | Showven | Sparkular Sparks Machine | Sparks Machine | 2CH | sparkular-user-manual.pdf |
| SHO | 229 | Showven | Sparkular Waver Sparks Machine | Sparks Machine | 6CH | SPARKULAR_WAVER_MANUAL.pdf |
| SHO | 009 | Showven | X-F1800 Circle Flamer Flame Machine | Flame Machine | 6CH | showven-circle-flamer-user-manual.pdf |
| SHO | 225, 226, 227 | Showven | cFlamer Quad Flame Machine | Flame Machine | 6CH-N, 6CH-M, 5CH-P | cFlamer Quad Manual.pdf |
| SHO | 213, 214, 215 | Showven | cFlamer mVolcano 5-Head Flame Machine | Flame Machine | 6CH-N, 6CH-M, 5CH-P | cFlamer mVolcano MANUAL.pdf |
| SHO | 011, 012, 013 | Showven | uFlamer Flame Machine | Flame Machine | 1CH-P, 6CH, 2CH-N | showven-uflamer-user-manual.pdf |
| SHO | 222, 223, 224 | Showven | uFlamer II Flame Machine | Flame Machine | 1CH-P, 6CH, 2CH-N | uFlamer II Manual.pdf |
| SHO | 047 | Showven | uFlamer Volcano 5-Head Flame Machine | Flame Machine | 6CH-M/PRO | uFlamer Volcano Manual.pdf |
| SHO | 228 | Showven | uFlamer X-Gasboom Flame Machine | Flame Machine | 6CH | uFlamer X-Gasboom Manual.pdf |
| SHO | 231 | Showven | Sparkular Triple Sparks Machine | Sparks Machine | 6CH | RMMAN087-SPARKULAR TRIPLE MANUAL -20250616.pdf |
| SHO | 232 | Showven | Sparkular Spin Sparks Machine | Sparks Machine | 4CH | RMMAN093-SPARKULAR SPIN MANUAL -20250616.pdf |
| SIG | 037, 038 | Sigma Services | 4-Head or 8-Head FireFly Flame Machine | Flame Machine | 8CH, 16CH | Firefly Manual with Four Channel Control_Revision 00_05_16_2017.pdf (Use one position for each head; assign the same DMX Channel Base to all positions; use the “Head 1” effects in the first position, the “Head 2” effects in the second, etc.) |
| SPK | 203 | Spark Fabrica | SF-01 Spark Rain Pro Sparks Machine | Sparks Machine | 2CH | SF-01 SPARK RAIN PRO USER MANUAL.pdf |
| SPK | 096 | Spark Fabrica | SF-05 Spark Jet Pro Sparks Machine | Sparks Machine | 2CH | SF-05 SPARK JET PRO USER MANUAL.pdf |
| SPK | 010 | Spark Fabrica | SF-180 Tornado Moving Head Flame Machine | Flame Machine | 6CH | spark fabrica moving head flamer user manual.pdf |
| SPK | 098 | Spark Fabrica | SF-90 I Flamer Plus Flame Machine | Flame Machine | 2CH | SF-90 FLAMER PLUS USER MANUAL.pdf |
| SPK | 097 | Spark Fabrica | SF-F5 Formula Flamer Flame Machine | Flame Machine | 6CH-B | SF-F5 FORMULA FLAMER MANUL.pdf |
| SPK | 099 | Spark Fabrica | SF-K2 Kungfupao Sparks Mine Machine | Sparks Mine Machine | 2CH | SF-K2 KUNGFUPAO USER MANUAL.pdf |
| SPK | 201 | Spark Fabrica | SF-X2 Spark Spin Sparks Machine | Sparks Machine | 4CH | SF-X2 SPARK SPIN USER MANUAL 2023.12.pdf |
| SPK | 202 | Spark Fabrica | SF-X8 Spark Titan Sparks Machine | Sparks Machine | 2CH | SF-X8 SPARK TITAN USER MANUAL.pdf |
| SPK | 200 | Spark Fabrica | SF-Z5 Flyspark Sparks Machine | Sparks Machine | 6CH | SF-Z5 FLYSPARK USER MANUAL.pdf |
| THO | 046 | Thomann | Fun Generation LED Pot 12x1W RGBW Par Light | Par Light | 6CH | thomann-377666-manual.pdf |
| TNG | 066 | Tengchang | Party Fog Jet Machine | Fog Jet Machine | 6CH | 1500W LED Fog Machine Manual.pdf |
| TOM | 027 | Tomshine | LED Gobo Moving Head | Moving Head | 9CH | tomshine-led-gobo-moving-head-manual.pdf |
| TOM | 028 | Tomshine | Mini Gobo Moving Head | Moving Head | 9CH | tomshine-mini-gobo-moving-head-manual.pdf |
| UKG | 087 | U King | B242X 30W Gobo Moving Head | Moving Head | 9CH | Moving Head DMX.pdf |
| UKG | 065 | U King | Mini Spider Light Moving Head | Moving Head | 15CH | spider-user-manual.pdf (Fixture has two bars each with four eyes of different colors: RGBW; the RGBW color components of standard effects apply to the corresponding eyes on both bars; the tilt of standard effects applies to the angle of both bars; if the physical fixture is configured with 1TIL and 2TIL opposite each other, the tilt of the standard effect will apply in opposing directions on the bars; drag the trajectory dots to the right to open the angle between the bars; the rest position of the bars is aiming straight forward, which corresponds to an angle DMX value of 170; dragging the trajectory dots to aim right 45°, opening up a 90° spread, corresponds to an angle DMX value of 85.) |
| UKG | 089 | U King | Pocket Moving Light Kaleidoscope + Laser Disco Ball | Disco Ball | 15CH | uking_pocket_moving_light.pdf |
| UKG | 029 | U King | RGBW Moving Head | Moving Head | 11CH | uking-manual.pdf |
| VEV | 210 | Vevor | BJY Cold Sparks Machine | Sparks Machine | 2CH | vevor-(BAGUO)coldsparkmachine-20240108_1732697193106.pdf |
| YFG | 081 | Yingfeng | Beam 230 Moving Head | Moving Head | 16CH | beam230-manual.pdf and yf-beam230-additional-documentation.pdf |
